Pressure Rating:500PSI

工作压力：500PSI

Temperature Range: -65°to 250°F (-54°to 120°C).

温度范围：-54℃到120℃

Three piece constrection--nut ,sleeve (or feeeule)and body

螺母，套管（或金属环）及体

Use with copper,aluminum, or plastic tubing (plastic requires 60P sleeve 61P insert)

使用铜，铝，或者塑料管连接

Standard fittings use short nuts .Long nuts are available for higher vibration applications. To buy compression fittings with long nut,please add a "1"in front of the part number .(i.e.68=168

标准接头使用短螺母，长螺母适用于需要高振频的接头中，如购买空压机用接头（长螺母），请在货号前加"1"

Easy to disassemble,no flaring tool required

易拆卸，无需扩口工具

Primary used: water .gasoline .oil and vacuum lines

适用对象：水、油、气以及真空设备等
